Alpinestars Supertech R10 Helmet - Element Carbon/Silver/Black – Medium (Part 8200324-1368-M)

Supertech R10 Helmet - Element - Carbon/Silver/Black - Medium

The Alpinestars Supertech R10 helmet is engineered for high-performance racing, combining advanced materials and aerodynamic design to provide optimal protection and comfort. Its outer shell utilizes molding technology with a multi-composite construction featuring a 3K high-density carbon outer layer, a uni-directional carbon composite layer, aramid fiber, and fiberglass. This layered composite assembly, bonded with epoxy resin, offers superior strength, energy dissipation, and a lightweight profile, ensuring effective impact absorption and limited outer shell deflection. The shell’s design promotes better energy spread over the EPS liner, enhancing safety during high-impact situations. Inside, an eight-piece multi-density EPS liner is strategically positioned with six different densities to optimize impact energy absorption across various zones, delivering reliable protection without compromising comfort. The liner's smooth, low-friction surface is specially coated to facilitate rotational and oblique impact management, allowing the helmet's interior to move independently relative to the rider's head, which significantly reduces transmitted force and the risk of concussion. The A-Head Fitment System grants riders precise adjustment of helmet height and tilt, ensuring a personalized fit that enhances both comfort and impact performance. Developed with CFD simulations and validated through wind tunnel testing, the helmet's aerodynamic features include two detachable spoilers—a standard and a race version—each fitted with elastic joints to detach during significant impacts, reducing rotational energy transfer. Lateral winglets further improve stability and aerodynamic drag, while turbulators on the visor enhance aero-acoustic performance. Ventilation is optimized with 11 intake and exhaust points, including chin, top, and rear ports, integrated with internal ducts that promote active airflow around the rider's head. Large top vents with adjustable sliders channel air effectively, and chin bar vents help prevent fogging by directing airflow over the shield. The helmet's design ensures efficient hot air removal through rear extractor vents, maintaining rider comfort during intense races. Overall, the Alpinestars Supertech R10 combines innovative materials, advanced impact mitigation systems, and aerodynamic efficiency to meet the demanding needs of professional racers seeking superior safety and performance.

Features:

• Multi-composite outer shell with 3K high-density carbon, uni-directional carbon, aramid fiber, and fiberglass for strength and energy dissipation

• Bonded layered construction with epoxy resin to maximize mechanical performance and reduce weight

• Eight-piece multi-density EPS liner with six strategically placed densities for excellent impact absorption

• Low-friction, smooth inner surface designed for superior oblique impact management and reduced rotational forces

• A-Head Fitment System allowing precise adjustment of helmet height and tilt for personalized fit

• Aerodynamic design developed with CFD and validated in wind tunnel and on-track testing, featuring detachable spoilers and lateral winglets

• Enhanced ventilation with 11 intake and exhaust points, including adjustable top vents and chin bar ports for optimal airflow

• Visor with turbulators to improve aero-acoustic performance and fog prevention

• Impact-absorbing elastic joints on spoilers to reduce rotational energy transfer during impacts
